Trotec BB20 Coating Thickness Meter

Trotec BB20 Coating Thickness Meter

Trotec BB20 Coating Thickness Meter

Precision instrument for fast, non-destructive coating thickness measurement on metal substrates

Product Description:

The Trotec BB20 is a professional-grade coating thickness meter designed for accurate, non-destructive measurement of coating thicknesses on both ferromagnetic (steel) and non-ferrous metal substrates (such as aluminum). With its dual-sensor system, the BB20 automatically identifies the substrate type and switches measurement mode accordingly.

This user-friendly device features a backlit display for easy readability in any lighting condition and stores up to 400 measured values in its internal memory. With high sensitivity and advanced calibration options, including a two-point calibration function, the BB20 ensures highly precise readings even on small or curved surfaces.

Designed for use in automotive inspections, industrial manufacturing, and quality control, the BB20 comes with calibration accessories and PC software, all neatly packed in a protective transport case.

Key Features:

• Dual-sensor system for automatic detection of ferromagnetic and non-ferrous substrates

• Non-destructive measurement of coating thickness

• Measurement memory for up to 400 readings (flash memory)

• Backlit display for enhanced readability

• Minimum measurement area:

  • Ferromagnetic substrates: Ø 7 mm

  • Non-ferrous-metallic substrates: Ø 5 mm

• Critical base layer thickness:

  • Ferromagnetic: 0.5 µm

  • Non-ferrous: 0.3 µm

• Minimum bending radius of measuring surface:

  • Ferromagnetic: 1.5 mm

  • Non-ferrous: 3 mm

• Display functions: Maximum, minimum, average, and standard deviation

• Two-point calibration for improved accuracy

• Acoustic alarm for configurable threshold alerts

• Automatic switch-off to preserve battery life

• Battery status indicator

Operating & Storage Conditions:

• Operating temperature: 0 °C to 40 °C

• Operating humidity: 20% to 90% RH

• Storage temperature: -20 °C to 60 °C

• Storage humidity: 20% to 90% RH

Scope of Delivery:

• BB20 coating thickness meter

• Calibration accessories

• USB cable

• Operating manual

• PC software

• Transport case

---

Summary:

• Purpose: Designed for accurate and efficient coating thickness measurement on metal substrates

• Measurement Memory: Stores up to 400 results for review and data logging

• Versatility: Measures on both ferromagnetic and non-ferrous metals

• Precision: Suitable for curved and small surfaces with small minimum measurement areas

• Applications: Ideal for automotive inspections, industrial quality control, and metal fabrication

Key Selling Points:
The Trotec BB20 offers precision, durability, and convenience in a compact tool. Its automatic substrate detection, high memory capacity, and calibration flexibility make it perfect for professionals who need accurate coating measurements on a wide variety of metallic surfaces.
