3NH YH1610 Color Haze Meter

3NH YH1610 Color Haze Meter

The 3NH YH1610 Color Haze Meter is a precision instrument engineered for comprehensive haze, transmittance, and color measurements in transparent and translucent materials. Designed to comply with major international standards, it is ideal for use in quality control and R&D across a range of industries including glass, plastics, films, displays, and packaging. With a high-resolution optical system and flexible measurement configurations, the YH1610 delivers fast, accurate, and reliable results.

Features

• Dual-Method Compliance

• High-Resolution Spectral System

• Multiple Aperture Selection
  Includes selectable measurement apertures (Φ20 mm, Φ15 mm, Φ8 mm, Φ4 mm) to accommodate different sample sizes and surface types.

• Open Measurement Area
  The design supports both vertical and horizontal testing orientations, improving versatility when measuring irregular or large samples.

• Full Transmittance Curve Capture
  Precisely captures the full transmittance curve of a sample, with the ability to output detailed chromaticity data including transmittance and haze.

• Robust Industrial Build
  Built with a Φ154 mm integrating sphere and high-grade components for long-term performance in demanding production or lab environments.

Application

• Glass Industry
  Suitable for testing architectural, automotive, and specialty glass for clarity, transmittance, and haze.

• Plastic and Film Production
  Used for quality control in plastic sheets, optical films, and packaging materials, ensuring visual and structural standards.

• Display and Touchscreen Manufacturing
  Measures haze and transmittance in optical coatings and display materials to ensure performance and transparency.

• Packaging Industry
  Verifies the optical properties of transparent and translucent packaging films for food, pharma, and consumer goods.

• Liquid Material and Chemical Analysis
  Enables trace transmission and color data output for liquid samples used in laboratory and industrial applications.

• Research & Development
  Ideal for testing new materials in academic and industrial R&D labs requiring spectral and optical precision.

Specification

• Product Model: YH1610 Color Haze Meter

• Geometry: Transmittance 0/D (parallel illumination, diffuse reception)

• Standard Compliance: ASTM D1003/1044, ISO 13468, ISO 14782, GB/T 2410, JJF 1303-2011, CIE 15.2, GB/T 3978, ASTM E308, JIS K7105, JIS K7361, JIS K7136

• Integrating Sphere Size: Φ154 mm

• Light Source: 400–700 nm combined LED light source (customizable wavelength extension)

• Spectrophotometric Mode: Concave grating

• Sensor: 256-pixel dual-array CMOS image sensor

• Wavelength Range: 400–700 nm (scalable customization available)

• Wavelength Interval: 10 nm

• Half Bandwidth: 10 nm

• Measurement Range: 0–100%

• Measuring Aperture: Φ20 mm / Φ15 mm / Φ8 mm / Φ4 mm (selectable)

• Sample Size: Thickness less than 105 mm
