AND LCS15K500 Compact Single Point Stainless Steel
🏗️ Product Overview: LCS15K500 Single Point Stainless Steel Load Cell (Tensile)
⭐ Product Summary AND LCS15K500 Compact Single Point Stainless Steel
-
Primary Function: A high-precision weight sensor specifically designed for tensile (hanging) weighing.
-
Construction: Made from anti-corrosion stainless steel.
-
Environmental Protection: Features an IP67 rating, ensuring reliability in the harshest and wettest industrial environments.
-
Typical Application: Provides stable weight measurement for tanks, hoppers, silos, and other vessels suspended from above.
✨ Key Features & Operational Advantages
-
Dedicated Tensile Design: Optimized exclusively for hanging load applications. Not suitable for compression use.
-
Stainless Steel (Corrosion Resistant): Offers superior corrosion resistance and long service life, especially in washdown and humid conditions.
-
IP67 Protection: Fully dust-tight and resistant to temporary immersion, guaranteeing reliable operation.
-
Eccentric Load Resistance: Maintains measurement accuracy even when the load is not perfectly centered.
-
Compact and Lightweight: Weighs only $0.8 \text{ kg}$, facilitating easy integration into existing systems.
⚙️ Technical Specifications
-
Model: LCS-15-K500
-
Rated Capacity: $5 \text{ kN}$ ($\approx 509.9 \text{ kg}$)
-
Usage Type: Tensile Use Only
-
Material: Stainless Steel
-
Protection Class (IP Rating): IP67
-
Operating Temperature Range: $-10^\circ \text{C}$ to $+40^\circ \text{C}$
-
Unit Weight: $0.8 \text{ kg}$
🎯 Typical Applications
-
Hanging Weighing Systems: Ideal for suspended tanks, silos, and hoppers.
-
Heavy and Wet Industries: Highly suitable for Food & Beverage Processing, Pharmaceutical, and Chemical industries.
-
Lifting Force Measurement: Can be used on overhead monorail scales and lift/suspension systems.
-
Inventory Control: Crucial for batching, filling, and inventory management operations in suspended vessels.
