Product Overview: AND LCS15T001 Compact Single Point Load Cell

The AND LCS15T001 is a high-performance, compact single-point load cell engineered for precision compression weighing in demanding industrial environments. With a substantial rated capacity of 1 tonne-force (10 kN), its robust stainless steel construction and superior sealing make it an ideal choice for tank, hopper, and platform scales where accuracy, durability, and resistance to harsh conditions are paramount.

---

Key Features & Operational Benefits

• True Single-Point Design: Ensures highly accurate weight measurement regardless of where the load is placed on the platform, effectively minimizing errors from eccentric or off-center loading.

• All-Welded Stainless Steel Construction: Provides exceptional resistance to corrosion, making it suitable for use in food processing, chemical, marine, and outdoor applications.

• IP67 Environmental Protection: Fully dust-tight and protected against temporary immersion in water, guaranteeing reliable operation in wet, humid, or dusty industrial settings.

• High Precision and Signal Stability: A consistent 2 mV/V output and minimal temperature drift ensure repeatable and trustworthy measurements over time.

• Dual Force Capability: While primarily optimized for compression applications, it is also capable of handling tensile (pulling) forces for versatile system integration.

• Robust Safety Margin: Features a safe overload limit of 150% of rated capacity, protecting the sensor from accidental overloading and ensuring long-term structural integrity.

• Flexible Excitation Voltage: Operates efficiently with a recommended input of 5-12 V DC, offering compatibility with a wide range of instrumentation.

---

Detailed Technical Specifications

• Model: AND LCS15T001

• Rated Capacity: 1 tf (10 kN)

• Rated Output (Sensitivity): 2.0 mV/V ± 0.1%

• Total System Accuracy (Combined Error): ≤ 0.03% of Rated Output

• Zero Balance: Within ±1% of Rated Output

• Insulation Resistance: ≥ 5000 MΩ (at 50 V DC)

• Temperature Compensation Range: -10°C to +40°C

• Temperature Effect on Performance:

  • On Zero: 0.016% of R.O. per 10°C

  • On Span (Output): 0.013% of Load per 10°C

• Safe Overload Rating: 150% of Rated Capacity

• Excitation Voltage:

  • Recommended Range: 5 – 12 V DC

  • Maximum Allowable: 15 V DC

• Electrical Resistances:

  • Input Resistance: 380 Ω ± 20 Ω

  • Output Resistance: 350 Ω ± 3.5 Ω

• Cable Specification: 4.5 meters in length, 5.0 mm outer diameter

• Product Weight: 3.0 kg

---

Primary Applications

This load cell is ideally suited for a wide range of industrial weighing systems, including:

• Tank and Hopper Weighing Systems for inventory management of liquids, powders, and granules.

• Heavy-Duty Industrial Platform and Bench Scales.

• Material Storage and Silo Monitoring Systems.

• Batching, Mixing, and Filling Equipment in process automation.

• Any application requiring high corrosion resistance and environmental durability.
