AREC 4 Digital Ceramic Hot Plate Stirrer Velp Scientifica

AREC 4 Digital Ceramic Hot Plate Stirrer Velp Scientifica

Product Description

The AREC 4 Digital is a compact and powerful hot plate stirrer featuring a 4-inch square ceramic plate, designed to deliver excellent performance in temperature-sensitive laboratory applications. With a maximum plate temperature of 550 °C, it ensures fast heating and superior chemical resistance for a wide range of laboratory workflows.

For precise sample thermoregulation, the AREC 4 Digital can be connected to Pt100, Pt1000 probes, or the VTF Digital thermoregulator. Using Pt100/Pt1000 probes, the instrument provides medium heating control up to 350 °C with ±1.0 °C accuracy. With the VTF Digital, it enables precise medium thermoregulation up to 300 °C with an outstanding accuracy of ±0.5 °C.

Compact yet versatile, the AREC 4 Digital is the ideal solution for laboratories requiring accuracy, safety, and durability in a small footprint.

Key Features

• 4-inch square ceramic plate offering excellent resistance to chemicals

• Maximum plate temperature: 550 °C

• External probe compatibility (Pt100, Pt1000, VTF) for superior thermoregulation

• High accuracy: ±0.5 °C with VTF and ±1.0 °C with Pt100/Pt1000

• SpeedServo™ torque compensation for constant stirring speed

• Digital user interface for easy monitoring and precise control

• Compact, lightweight, and robust design

Applications

• Temperature-sensitive laboratory reactions

• Chemical synthesis and sample preparation

• Academic, research, and industrial laboratories

• Quality control and analytical workflows

• Experiments requiring precise heating and stirring with small to medium volumes

Technical Specifications

• User interface: Digital

• Housing material: Aluminum body, technopolymer enclosure

• Plate material: Ceramic

• Plate dimension: 100 × 100 mm (4 × 4 in)

• Stirring volume (H2O): 5 L

• Stirring speed range: 100 – 1500 rpm

• Speed control: Digital with SpeedServo™ torque compensation

• Motor: Brushless

• Temperature range: Room temp – 550 °C

• Heating control: Digital

• Temperature setting resolution: 1 °C

• External temperature sensor connection: Pt100, Pt1000, VTF

• Thermoregulation range: Room temp – 350 °C

• Thermoregulation accuracy: ±0.5 °C (VTF), ±1.0 °C (Pt100, Pt1000)

• Hot plate warning system: On-display alert when plate exceeds 50 °C

• Power input: 280 W

• Weight: 1.9 kg (4.2 lb)

• Dimensions (W × H × D): 160 × 100 × 270 mm (6.3 × 3.9 × 10.6 in)

Conclusion

The Velp Scientifica AREC 4 Digital is the ideal choice for laboratories seeking a compact, reliable, and precise hot plate stirrer. With its robust ceramic surface, advanced thermoregulation capabilities, and user-friendly digital interface, it ensures maximum reproducibility and safety for a wide range of applications.
