Biobase Centrifuge BKC-TL4X

Biobase Centrifuge BKC-TL4X

Introduction

The Biobase Centrifuge BKC-TL4X is a compact and efficient tabletop low-speed centrifuge designed for versatile laboratory applications. Powered by a microcomputer processor and equipped with an OLED display, it offers real-time monitoring of operating parameters, ensuring optimal performance. The centrifuge features adjustable acceleration and deceleration levels, a brushless DC motor for maintenance-free operation, and advanced cooling mechanisms for temperature stability. It also includes safety features such as door locks and unbalance detection, making it a reliable choice for various laboratory settings.

Features

• Microcomputer Control: The centrifuge is controlled by a microcomputer processor, providing precision and efficiency in operation. The OLED display shows all operating parameters in real-time for easy monitoring.
• Adjustable Acceleration and Deceleration: Offers 10 levels each for both acceleration and deceleration, allowing the user to fine-tune the centrifugation process for specific applications.
• Brushless DC Motor: Ensures dust-free, maintenance-free operation with minimal noise and vibration, enhancing reliability and extending the lifespan of the unit.
• Efficient Cooling Design: The unique cooling system ensures the sample temperature rises by only 5°C when running at speeds below 4000 rpm for extended periods, maintaining the integrity of sensitive samples.
• Program Storage: Capable of storing up to 20 sets of centrifugation programs, offering convenience and consistency for repetitive tasks.
• Safety Features: Includes a door lock, over-temperature protection, and unbalance detection to ensure safe and reliable operation at all times.
• User-Friendly Interface: The interface is designed to be concise, clear, and intuitive, making it easy to operate, even for users with minimal experience.

Application

The Biobase Centrifuge BKC-TL4X is ideal for a range of laboratory applications, including:

• Scientific Research: Used for particle separation, cell cultures, and other research applications requiring efficient centrifugation.
• Medical Laboratories: Ideal for blood sample processing, plasma separation, and other diagnostic tasks.
• Biotechnology and Pharmaceutical Industries: Useful in the separation and purification of chemicals, proteins, and other pharmaceutical compounds.
• Education and Training: A valuable tool for academic and training purposes, helping students and professionals learn the fundamentals of centrifugation.

Technical Specifications

• Model: BKC-TL4X
• Max. Speed: 4000 rpm
• Max. RCF: 2250 × g
• Max. Capacity: 24 × 10 ml
• Speed Precision: ±20 rpm
• Time Range: 1 second to 999 minutes
• Power Supply: AC 220V, 50/60 Hz (Standard); 110V, 60 Hz (Optional)
• Power Consumption: 200 W
• Noise Level: ≤65 dB
• External Size (L×W×H): 350 × 400 × 270 mm
• Package Size (L×W×H): 410 × 510 × 310 mm
• Net Weight: 18 kg
• Gross Weight: 20 kg

Rotor Specifications

The BKC-TL4X centrifuge is compatible with various rotor options to accommodate different sample types and volumes:

• Angle Rotor 12 × 15 ml: Max Speed 4000 rpm, Max RCF 2200 × g
• Angle Rotor 24 × 10 ml: Max Speed 4000 rpm, Max RCF 2250 × g

Conclusion

The Biobase Centrifuge BKC-TL4X is a high-performance, user-friendly centrifuge ideal for low-speed applications in scientific research, medical diagnostics, biotechnology, and education. Its compact design, maintenance-free operation, and advanced features such as adjustable acceleration, safety protections, and program storage make it a versatile and reliable tool for laboratories of all sizes.
