Biobase Digital Display Viscometer BDV-5SC

Biobase Digital Display Viscometer BDV-5SC

The Biobase BDV-5SC Digital Display Viscometer is a high-performance, microcomputer-controlled instrument designed for precise viscosity measurement of Newtonian and non-Newtonian fluids. It features an intuitive 5-inch LCD color touchscreen and automatic test modes, making it ideal for laboratories and industries requiring accurate and user-friendly viscosity testing.

Features

1. Automatic test functionality allows the rotor to stop automatically when a stable measurement is reached.

2. Built-in data storage function enables easy recording and review of test results.

3. 5-inch LCD color touchscreen for intuitive parameter display and simple operation.

4. Equipped with RS232 interface for direct connection to a printer, allowing instant data output.

5. Real-time temperature monitoring through a dedicated temperature sensor interface.

6. USB computer interface for easy data transfer and computer connectivity.

7. Microcomputer control ensures high sensitivity, reliable testing, and strong anti-interference performance.

8. Universal joint rotor connection for smoother rotation and easy handling.

9. Durable handwheel made of high-performance engineering plastic and stainless steel for ease of use and longevity.

10. Dual-language display (Chinese and English), freely switchable.

11. Suitable for measuring the absolute viscosity of Newtonian liquids and the apparent viscosity of non-Newtonian liquids.

Applications

• Research laboratories in chemical, food, cosmetics, and pharmaceutical industries

• Quality control of oils, lubricants, and adhesives

• Academic and educational laboratory settings

• Industrial R&D departments for viscosity-related analysis

• Production environments requiring consistent fluid behavior monitoring

• Paints, resins, polymers, and other viscosity-sensitive products

Specifications

• Model: BDV-5SC

• Measured range: 1 to 1 × 10⁵ mPa.s

• Measurement accuracy: ±2% (FS) for Newtonian fluids

• Repetitive error: 1% (FS) for Newtonian fluids

• Display accuracy: 0.01 mPa.s

• Automatic single measurement: Rotor stops automatically once stable

• Rotor specification: Standard 1#, 2#, 3#, 4# (Optional 0# for low viscosity)

• Rotor speed (rpm): 6, 12, 30, 60

• Standard accessories: Temperature sensor interface, computer USB interface, RS232 interface

• Work environment: Temperature 5–35°C, relative humidity ≤80%

• Power supply: AC 110–240V, 50/60Hz, DC 12V

• Package size (W×D×H): 200 × 440 × 480 mm

• Net weight: 6.3 kg

• Gross weight: 10.6 kg

Conclusion

The BDV-5SC Digital Display Viscometer from Biobase is a versatile and efficient solution for precise viscosity analysis. With a modern touchscreen interface, smart control features, and multiple connectivity options, it simplifies the testing process while maintaining high measurement accuracy. This viscometer is well-suited for laboratories and production facilities that require reliable and easy-to-use viscosity measurement tools.
