Product Description and Specifications – Fluke 754 Process Calibrator

---

Overview Fluke 754 Process Calibrator:

The Fluke 754 Process Calibrator is an advanced documenting process calibrator integrated with full HART communication capabilities, making it a powerful all-in-one tool for calibrating, maintaining, and troubleshooting HART-enabled process instrumentation. Designed for rugged industrial use, the Fluke 754 streamlines work processes, ensures high accuracy, and allows technicians to automate calibration tasks and efficiently document results.

---

Key Features Fluke 754 Process Calibrator:

• Combines a HART communicator and multifunction calibrator into a single, rugged handheld device.

• Supports automated as-found/as-left calibration procedures, improving consistency and traceability for quality compliance.

• Can simulate, measure, and source multiple parameters including current, voltage, temperature (RTDs and thermocouples), resistance, frequency, and pressure.

• Compatible with Fluke 700Pxx Pressure Modules, enabling pressure measurement and sourcing.

• Handles fast pulse RTD transmitters and PLCs with pulse widths as short as 1 ms.

• Offers built-in tools for one-point and two-point switch testing, square root DP flow testing, and custom measurement configurations.

• Supports user-entered values, programmable delays, and other advanced features for field flexibility.

• Bright dual white display shows both measured and sourced values at the same time.

• Features an easy-to-navigate multilingual interface, enhancing usability for global operators.

• Stores up to one week of downloaded procedures and calibration results for field use without needing a computer.

• Includes a rechargeable Li-Ion battery that provides over 8 hours of continuous operation.

• Delivered with DPC/Track Sample software for data management and report generation.

• Compatible with a wide range of asset management software platforms.

• Backed by a three-year warranty for long-term reliability.

---

Specifications:

• Supports measurement of current, frequency, pressure, resistance, temperature, and voltage.

• Operating temperature range: -10°C to +50°C.

• Storage temperature range: -20°C to +60°C.

• Operates up to 3000 meters above sea level.

• Can record up to 8000 readings for traceable documentation.

• Internal memory holds one week of calibration procedures and results.

• Battery life exceeds 8 hours in typical field conditions.

• Built with IP52 protection against dust and dripping water.

• Dimensions: 136 x 245 x 63 mm.

• Weight: 1.2 kg, portable yet durable for field applications.

---

Summary:

The Fluke 754 Process Calibrator is a complete field solution for process technicians who need to perform a wide range of tasks with one rugged, reliable instrument. With its built-in HART communicator, automation capabilities, long battery life, and broad compatibility with various parameters and pressure modules, the 754 helps streamline operations and improve calibration accuracy in regulated and high-performance environments. Ideal for process plants, service providers, and maintenance professionals who demand precision and documentation in a single tool.
