Fluke 985 Particle Counter

Fluke 985 Particle Counter

Fluke 985 Particle Counter
Advanced Air Quality Monitoring Tool

Product Description

The Fluke 985 Particle Counter is a high-performance air quality monitoring instrument designed for facility maintenance, HVAC professionals, and cleanroom validation. With six channels and a wide particle size range, it offers accurate, real-time measurement to ensure indoor air quality and compliance with ISO Class 5–9 standards. This compact, ergonomic device features a large color display, long battery life, and flexible data handling and export options.

Key Features Fluke 985 Particle Counter

• Six particle size channels (0.3 to 10.0 µm): Ensure accurate particle measurement, even in critical environments requiring ISO Class 5–9 certification.

• Lightweight and ergonomic: One-hand operation in tight or hard-to-reach spaces without user fatigue.

• Long battery life: Up to 10 hours of standard use, ideal for a full day’s work.

• 3.5-inch QVGA color screen: Easy-to-navigate interface with large fonts and intuitive icons.

• 10,000-record memory: Rapid access to historical data for analysis and reporting.

• On-screen data visualization: View data in table or bar graph format based on user preference.

• Customizable settings: User-defined display options, sampling methods, and alarm configurations.

• Multiple data export options: Transfer data via USB flash drive, USB cable, or Ethernet without requiring proprietary software.

• Optional password control: Enhances security when needed.

• USB/Ethernet charging dock: Keeps the device ready for use at all times.

Technical Specifications Fluke 985 Particle Counter

• Particle size channels: 0.3 μm, 0.5 μm, 1.0 μm, 2.0 μm, 5.0 μm, 10.0 μm

• Flow rate: 0.1 cfm (2.83 L/min)

• Light source: 775–795 nm, 90 mW class 3B laser

• Counting modes: Raw count, #/m³, #/ft³, #/L (Cumulative or Differential)

• Counting efficiency: 50% at 0.3 μm; 100% for particles >0.45 μm (ISO 21501 compliant)

• Zero count: 1 count per 5 minutes (JIS B9921 standard)

• Maximum concentration limit: 10% at 4,000,000 particles/ft³

• Data storage: 10,000 samples (circular buffer)

• Alarms: Particle count alert, low battery, sensor failure

• Delay timer: 0 to 24 hours

• Sample inlet: Isokinetic probe

• Security: Optional administrator password control

• Communication: USB or Ethernet

• Dimensions: 27.2 cm × 9.9 cm × 5.3 cm (10.7 in × 3.9 in × 2.1 in)

• Weight: 0.68 kg (1.5 lb)

• Power adapter: 100–240 V AC input, 12 V DC output, 2.5 A

• Battery: Rechargeable Li-ion 7.4 V, 2600 mAh; approx. 10 hours standard use (5 hours continuous sampling), full recharge in 3.5 hours

• Calibration: PSL particles in air (NIST traceable)

• Operating conditions: 10 °C to 40 °C (50 °F to 104 °F), <95% RH non-condensing

• Storage conditions: -10 °C to 50 °C (14 °F to 122 °F), up to 98% RH non-condensing

• Warranty: One year

Included Accessories

• Charging/communication dock with USB and Ethernet support

• 7 ft ENET CAT5E cable

• 6 ft USB-A to Mini-B cable

• 12 V DC power adapter

• Zero-count inlet filter

• Filter adapter

• Sample inlet protective cap

• Hard case

• Quick Start Guide and User Manual CD

---

Summary

Overview:
The Fluke 985 Particle Counter provides precise and reliable particle measurements for air quality monitoring in professional environments.

Key Selling Points:

• ISO-compliant multi-channel particle detection

• Portable with long battery life

• Flexible data management and export

• User-friendly display and interface

• Ideal for cleanroom and HVAC inspection
