High temp drying oven J-DH1 Jisico

High Temperature Drying Oven J-DH1 Jisico

Product Description

The Jisico J-DH1 High Temperature Drying Oven is a precision-engineered laboratory oven designed for applications requiring stable and uniform high-temperature performance. Utilizing a gravity convection system, it ensures gentle air circulation for even heat distribution, making it ideal for drying, baking, sterilizing, and heat treatment processes.

Constructed with a stainless steel inner chamber and a powder-coated steel exterior, the J-DH1 offers durability and resistance to corrosion. The oven operates within a wide temperature range from Ambient +10°C up to 300°C, with a practical working range of 60°C to 280°C. Controlled by a PID system with SSR regulation, it guarantees accurate temperature control and consistent performance.

Equipped with high-grade insulation, safety devices, and user-friendly features, this model provides reliable and safe operation for laboratories, industrial settings, and research facilities.

Key Features

• Gravity convection system for even heat distribution

• Wide temperature range: Ambient +10°C to 300°C (usable up to 280°C)

• High-precision PID controller with SSR regulation

• High-grade insulation using glass wool and rock wool for thermal efficiency

• Self-diagnostic safety system with overheat and short circuit protection

• Timer function up to 99 hours 59 minutes or continuous operation

• High-temperature foamed silicone rubber door packing for sealing integrity

• Durable stainless steel chamber and powder-coated steel exterior

• Ventilation holes for optimal air exchange and temperature control

Applications

• Heat treatment and drying of laboratory samples

• Baking, curing, and material conditioning

• Stability and endurance testing of components

• Sterilization and moisture removal in research and industrial settings

Specifications

• Model: J-DH1

• Type: Gravity convection system

• Overall Dimensions (W×D×H): 620 × 600 × 870 mm

• Chamber Dimensions (W×D×H): 450 × 450 × 450 mm

• Capacity: 91 liters

• Temperature Range: Ambient +10°C to 300°C

• Using Range: 60°C to 280°C

• Accuracy: ±1.0°C at 100.0°C

• Controller: PID controller

• Regulator: SSR type

• Thermocouple: K type (CA)

• Heater: 2,500 W (Ni-Cr)

• Insulation: Glass wool and rock wool

• Timer: 99 hr 59 min or infinity

• Door Packing: High temperature grade foamed silicon rubber

• Safety Devices: Self-diagnosis (memory error, overheating, SSR short circuit, sensor short circuit), ELB

• Shelves: 3 ea

• Ventilation Hole: Ø34 × 2 mm

• Interior Material: Stainless steel plate

• Exterior Material: Steel plate with powder-coated finish

• Power Source: AC 230V, 50/60Hz, 1 phase

• Net Weight: 62.6 kg

Conclusion

The Jisico J-DH1 High Temperature Drying Oven delivers reliable high-heat performance with excellent temperature uniformity and safety. Its robust construction, precise control system, and efficient insulation make it a dependable choice for laboratories and industries requiring consistent, high-quality drying and heat treatment operations.
