Lutron VB-8202 – Precision Industrial Vibration Meter

Lutron VB-8202 – Precision Industrial Vibration Meter

The Lutron VB-8202 is a high-precision vibration measurement device specifically engineered for monitoring the condition of industrial machinery. With its broad measurement range, detailed analysis capabilities, and accurate sensor system, it helps detect early signs of issues such as imbalance, misalignment, and structural looseness—enabling preventive maintenance and minimizing machine downtime.

---

Why Vibration Monitoring Matters

Vibrations in industrial machines are often the first warning signs of deeper problems. If left unaddressed, issues like imbalance or looseness can lead to component failure, production losses, and serious safety hazards. The Lutron VB-8202 provides a reliable and professional solution for these challenges, ensuring timely detection and action.

---

Key Benefits Lutron VB-8202 – Precision Industrial Vibration Meter

• Early Problem Detection: Covers a frequency range from 10 Hz to 1 kHz to identify imbalance, misalignment, or looseness in rotating machinery.

• Detailed Vibration Analysis: Measures both RMS (Root Mean Square) and Peak values, providing deeper insights into the nature and severity of vibration.

• Preventive Maintenance Planning: Enables accurate condition monitoring for scheduling timely maintenance, extending equipment lifespan, and reducing repair costs.

---

Main Features Lutron VB-8202 – Precision Industrial Vibration Meter

• Wide Measurement Range with High Accuracy:

  • Velocity: 0.5 to 199.9 mm/s

  • Acceleration: 0.5 to 199.9 m/s²

  • Accuracy: ±(5% + 2 digits) at 160 Hz and 80 Hz under standard conditions (23 ± 5℃)

• Large LCD Display:

  • Screen size: 61 mm x 34 mm

  • Digit size: 15 mm (0.6 inch) for easy readability in noisy or dim environments

• RMS and Peak Mode: Supports both RMS and Peak measurements to enable detailed trend and fault analysis.

• Data Hold Function: Allows freezing of the current reading for easy recording and review.

• Memory for Maximum and Minimum Readings: Automatically records the highest and lowest vibration levels for trend tracking.

• RS-232 Data Output: Enables data transfer to external devices for advanced analysis and reporting.

• User-Friendly Design:

  • Simple interface and well-placed buttons for easy operation

  • Suitable for professionals and non-expert users alike

• Power-Saving Functionality:

  • Auto shut-off preserves battery life when not in use

  • Manual power off also available

---

Target Users

• Maintenance Engineers: For regular monitoring and diagnostics of machine health

• Plant Managers: To optimize equipment performance and reduce downtime

• Mechanical Technicians: For efficient troubleshooting and repair planning

• Quality Inspectors: To ensure machine stability and operational safety

• Manufacturing Industry: For use on production lines and rotating machinery

• Automotive Sector: To assess engine vibrations and component wear

• Energy Sector: To monitor turbines, generators, and power plant machinery

---

Technical Details

• Frequency Range: 10 Hz to 1 kHz

• Measurement Type: RMS and Peak

• Display Type: Super large LCD

• Power Supply: 9V DC battery (006P, MN1604, PP3 or equivalent)

• Power Consumption: Approx. 6 mA

• Operating Temperature: 0 to 50°C (32 to 122°F)

• Humidity Tolerance: < 80% RH

---

Device and Accessories Dimensions

• Main Unit: 180 x 72 x 32 mm (7.1 x 2.8 x 1.3 inch), 230 g (0.50 lb)

• Vibration Probe: 36 mm diameter x 71 mm length

• Sensing Head: 8.9 mm diameter x 42 mm length

• Cable Length: 1.2 meters

• Probe with Sensing Head Weight: 165 g (0.36 lb)

---

Included Accessories

• Instruction Manual – 1 PC

• Cable with Plugs – 1 PC

• Vibration Probe – 1 PC

• Sensing Head – 1 PC

• Magnetic Base – 1 PC

• Carrying Case – 1 PC

---

Optional Accessories

• Data Acquisition Software for Windows (SW-E816)

• RS-232 Cable (UPCB-01)

• USB Cable (USB-01)

---

Summary

The Lutron VB-8202 Industrial Vibration Meter is a professional-grade tool designed to monitor and diagnose machine vibrations with high precision. Its wide measurement range, RMS and Peak detection modes, RS-232 data output, and easy-to-use interface make it ideal for engineers, technicians, and maintenance teams across various industries. Whether in manufacturing, automotive, or energy sectors, the VB-8202 helps ensure machinery runs reliably, safely, and efficiently—preventing costly breakdowns and production losses.
