Sauermann Inclined Liquid Column Manometers MT 40

Sauermann Inclined Liquid Column Manometer MT 40

Product Description

The Sauermann MT 40 is a compact inclined liquid column manometer designed for precise differential pressure measurement in low-pressure applications. Built with a safety reservoir, the MT 40 allows for temporary overshooting of the scale without damaging the instrument. It features zero adjustment via a movable slide strip, an integrated spirit level for accurate horizontal positioning, and valve connectors for secure operation. With magnetic fixations and a support base plate, the MT 40 is versatile for both portable and fixed installations. Additionally, it can be used with a Pitot tube for measuring air velocity, making it suitable for HVAC and ventilation applications.

Key Features

1. Inclined liquid column design for precise low-pressure measurement

2. Safety reservoir for protection against scale overshoot

3. Zero adjustment via sliding strip for calibration accuracy

4. Integrated spirit level to ensure proper horizontality

5. Equipped with valve connectors, magnetic fixations, and base plate support

6. Compatible with Pitot tubes for air velocity measurement

Applications

1. Air velocity measurement in HVAC systems using Pitot tubes

2. Differential pressure measurement in ventilation systems

3. Laboratory testing and calibration requiring low-pressure accuracy

4. Monitoring cleanroom or filter performance

5. Industrial process control involving low differential pressures

Technical Specifications (MT 40)

1. Measuring range: 0–40 mmCE (differential pressure)

2. Manometer type: inclined liquid column manometer

3. Manometric liquid: VOLT 1S, density 1.86 at 20 °C

4. Maximum static pressure: 6 bars

5. Reservoir capacity: 20 ml

6. Operating temperature range: -30 °C to +60 °C

7. Dimensions: 208 × 93 × 37 mm

8. Weight: 800 g

9. Mounting: magnetic fixation and base plate support

10. Connections: equipped with valve connectors

Conclusion

The Sauermann MT 40 inclined liquid column manometer delivers high-precision differential pressure measurement with added safety and versatility. Its protective reservoir, integrated spirit level, and compatibility with Pitot tubes make it an excellent tool for HVAC professionals, laboratories, and industrial environments requiring accurate and reliable monitoring of low pressures and air velocities.
