Sauermann Inclined Liquid Column Manometers VH Series

Sauermann Inclined Liquid Column Manometers VH Series

Product Description

The Sauermann VH Series inclined liquid column manometers are designed for accurate measurement of low differential pressures. Featuring a horizontal V-shaped liquid column, they allow dual measurement ranges with excellent sensitivity. The integrated spirit level ensures correct horizontality, while the zero point can be easily adjusted using the float system. With compact dimensions and robust construction, the VH Series is suitable for both fixed installations and portable use.

Key Features

1. Horizontal V-shaped liquid column for precise low-pressure readings

2. Dual measurement range for flexible applications

3. Zero adjustment via float for calibration accuracy

4. Compact design with integrated spirit level for easy alignment

5. Wall-mounted installation with optional PVC support

6. Designed for reliability and simple operation

Applications

1. Monitoring differential pressure in HVAC systems

2. Ventilation and cleanroom air pressure measurement

3. Airflow and filter monitoring

4. Laboratory and process control applications

5. Portable or fixed pressure measurement tasks

Technical Specifications

1. Differential pressure range (VH 50): 0–50 mmCE / 0–500 Pa

2. Manometer type: inclined liquid column manometer

3. Manometric liquid: AWS 10 red oil, density 0.87 at 15 °C

4. Maximum static pressure: 1 bar

5. Reservoir capacity: 20 ml

6. Mounting: wall-mounted, with or without white PVC support

7. Operating temperature: -30 °C … +60 °C

Conclusion

The Sauermann VH Series inclined liquid column manometers are compact, precise, and versatile instruments for low differential pressure measurement. With dual ranges, easy zero adjustment, and an integrated spirit level, they provide reliable results in HVAC, laboratory, and industrial applications.
