Sauermann Multi-parameter transmitters Si-ATE320

Sauermann Multi-parameter transmitters Si-ATE320

The Sauermann Si-ATE320 Multi-Parameter Transmitter is designed for precise monitoring of key environmental parameters in various industrial and HVAC applications. It measures essential values such as air velocity, differential pressure, temperature, relative humidity, and gas concentrations (CO, VOC, CO₂). Its robust design, graphic touch display, and IP66 protection make it suitable for demanding environments, while its Modbus compatibility ensures smooth integration with monitoring systems.

Features

1. Measures multiple parameters including air velocity, CO, VOC, CO₂, differential pressure, temperature, and humidity.

2. High durability with IP66 rating and VHP (Vaporized Hydrogen Peroxide) resistance for harsh environments.

3. Graphic touch display for easy reading and configuration.

4. Modbus network compatibility for efficient system integration.

5. Accurate and stable performance within 0–50°C operating range.

6. Compact and lightweight design for flexible installation options.

Applications

1. HVAC system performance monitoring.

2. Industrial environmental control and safety checks.

3. Cleanroom and laboratory airflow validation.

4. Indoor air quality assessment.

5. Energy optimization in ventilation systems.

6. Facility compliance with environmental regulations.

Specifications

• Units: ACH, dam³/h, fps, inWc, ppb, °Ctf, °F, °Ftf, °C, % RH, °Ctw, °Ctd, °Ftd, °Ftw, Pa, m³/s, PSI, kPa, ppm, g/m³, g/kg, kj/kg, m/s, mbar, l/s, hPa, m³/h, mmH₂O, mmHg, daPa, cfm

• Alarm: Buzzer (60 dB at 10 cm)

• Display: Graphic touch display

• Protection: IP66, VHP resistant

• Standards: RoHS 3 (2015/863 EU), UKCA, WEEE, EMC, Low Voltage Directive

• Power Supply: 24 VAC/VDC ±10%

• Ethernet: No

• Modbus: Yes

• Dimensions: 100 × 47 × 234 mm

• Weight: 700 g

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -10°C to 70°C

Conclusion

The Sauermann Si-ATE320 Multi-Parameter Transmitter offers reliable, accurate, and versatile measurement capabilities for critical environmental monitoring needs. Its rugged build, ease of use, and multi-parameter functionality make it an excellent choice for industries requiring precise control of air quality and environmental conditions.
