Sauermann Vertical Liquid Column Manometers TJ 100

Sauermann Vertical Liquid Column Manometer TJ 100

Product Description

The Sauermann TJ 100 is a vertical liquid column manometer designed for measuring pressure, depression, or differential pressure of air and gases. Its “J”-shaped column provides direct readings, while the zero adjustment is achieved by moving the graduated slide strip. The TJ 100 can be used for both fixed and portable applications, depending on the manometric liquid used (AWS 10 or VOLT 1S). It is supplied with a white PVC support, screws, rawlplugs, connectors, and a bottle of liquid, ensuring a ready-to-use solution.

Key Features

1. “J”-shaped vertical column for direct pressure and depression measurement

2. Measuring range: 0–100 mmH₂O (0–10 mbar or 0–1000 Pa) with AWS 10 liquid

3. High accuracy with 1 mmH₂O or 0.5 mbar resolution

4. Zero adjustment by sliding the graduated strip

5. Suitable for fixed or portable applications

6. Durable Altuglas body and liquid column construction

Applications

1. HVAC systems for pressure and airflow monitoring

2. Gas and air pressure control in industrial processes

3. Laboratory and cleanroom differential pressure measurement

4. Calibration and verification of low-pressure systems

5. Education and training in fluid mechanics and instrumentation

Technical Specifications (TJ 100)

1. Differential pressure range: 0–100 mmH₂O (0–10 mbar / 0–1000 Pa) with AWS 10 liquid

2. Resolution: 1 mmH₂O or 0.5 mbar

3. Manometer type: vertical liquid column (“J”-shaped)

4. Manometric liquid: AWS 10 (density 0.86) or VOLT 1S (density 1.86)

5. Maximum static pressure: 6 bars

6. Recommended use temperature: +5 °C to +30 °C

7. Possible use temperature: -30 °C to +60 °C

8. Manometer body: 15 mm transparent Altuglas

9. Zero adjustment: movable graduated slide strip, 15 mm travel

10. Connections: Ø 5 x 8 mm crystal tube on Ø 6.2 mm nickel-plated brass connectors

11. Mounting: wall-mounted with or without PVC support

Dimensions (TJ 100)

• Length (a): 57 mm

• Height (b): 185 mm

• Depth (c): 25 mm

• Base width (d): 25 mm

• Column height (e): 147 mm

• Distance between tubes: 171 mm

• Weight: 290 g

Conclusion

The Sauermann TJ 100 is a compact and versatile vertical liquid column manometer, ideal for accurate low-pressure measurements in HVAC, industrial, and laboratory applications. Its robust construction, ease of zero adjustment, and adaptability for both fixed and portable use make it a reliable choice for professionals requiring precision in monitoring air and gas pressures.
