SH Scientific Homo Disperser SH-HD-Set

SH Scientific Homo Disperser SH-HD-SET

Product Description

The SH-HD-SET Homo Disperser from SH Scientific is designed for efficient homogenizing, mixing, and dispersing applications in laboratories and research facilities. It delivers reliable performance for processing liquids, suspensions, and emulsions that require uniform particle distribution.

The system uses a brushless DC motor to provide stable rotation and long operational life. The digital PID feedback controller ensures precise speed regulation and smooth operation during homogenization. Users can easily monitor and control the process through a high-fidelity 3.5-inch touch color LCD display.

This disperser supports programmable operation with multiple steps, allowing laboratories to automate complex mixing procedures. Real-time monitoring of motor temperature and current helps maintain safe operation. Data can also be stored and transferred through the USB port for process tracking and analysis.

The dispersing tool uses stainless steel materials, ensuring durability and resistance to corrosion. With a maximum processing volume of up to 5 liters, the SH-HD-SET is suitable for laboratory research, chemical processing, and sample preparation.

Features

• Speed range from 500 to 8,000 rpm without load
• Speed control resolution of 10 rpm for precise adjustment
• Maximum processing volume up to 5 liters of water
• Brushless DC motor for stable operation and long service life
• Digital PID feedback controller for accurate speed control
• Forward and reverse operation with automatic program switching
• 3.5-inch touch color LCD display for clear monitoring
• Real-time monitoring of motor temperature and current
• USB port for real-time monitoring and data backup
• Programmable operation with 9 programs and 11 steps
• Favorite setting function for up to 8 stored configurations
• Safety system with overload, current, and heat protection

Applications

• Homogenizing chemical solutions and suspensions
• Dispersing powders into liquids
• Emulsion preparation in pharmaceutical research
• Sample preparation in biotechnology laboratories
• Cosmetic and food formulation development
• Research and development laboratory testing

Specifications

• Model: SH-HD-SET
• Speed Range: 500 – 8,000 rpm (without load)
• Speed Control Resolution: 10 rpm
• Maximum Volume (H₂O): 5 L
• Motor Type: Brushless DC motor
• Motor Wattage: 300 W
• Power Consumption: 350 W
• Working Direction: Forward and reverse (programmable)
• Controller: Digital PID feedback control with high performance MCU
• Timer: Up to 99 hr 59 min
• Display: 3.5-inch touch color LCD
• Turbine Material: SUS316
• Shaft Material: SUS304
• Permissible Temperature and Humidity: 5℃ to 40℃, <80% RH
• Dimensions: 80 × 185 × 260 mm
• Net Weight: 10.39 kg
• Packing Size: 290 × 800 × 180 mm
• Gross Weight: 12.14 kg
• Power Supply: 1 phase, AC 120 V 60 Hz or AC 230 V 50/60 Hz
• Accessories: SH-HDT, SH-OSSR040

Conclusion

The SH-HD-SET Homo Disperser offers precise speed control, programmable operation, and strong safety features. Its durable stainless steel components and advanced digital control system make it suitable for demanding laboratory homogenizing and dispersing applications.
