SH Scientific Vacuum Pump SH-CV20

SH Scientific Vacuum Pump SH-CV20

Product Description

The SH-CV20 vacuum pump from SH Scientific is a compact oil rotary vacuum pump designed for reliable vacuum generation in laboratory and industrial applications. It provides stable pumping performance and efficient air evacuation for systems that require consistent vacuum conditions.

The pump offers a pumping speed of 167 L/min, allowing rapid evacuation of gases from laboratory equipment and vacuum chambers. It can achieve an ultimate total pressure of 5 × 10⁻¹ Pa without gas ballast and 3 Pa when the gas ballast is in operation. This feature allows the pump to handle both dry gases and processes involving moisture or condensable vapors.

The SH-CV20 operates with a single-phase power supply and uses a 3/4 HP motor. The pump includes KF25 inlet and exhaust ports, which allow secure connection to standard laboratory vacuum systems. The oil rotary mechanism is supported by an oil capacity of 0.75 liters, ensuring proper lubrication and stable operation.

Its compact design, efficient motor speed, and relatively low noise level make the SH-CV20 suitable for continuous operation in laboratory environments.

Features

• Oil rotary vacuum pump with stable performance

• Pumping speed up to 167 L/min

• Ultimate pressure down to 5 × 10⁻¹ Pa without gas ballast

• Gas ballast function for handling vapors

• Single-phase motor operation

• KF25 inlet and exhaust connections

• Compact design suitable for laboratory environments

• Low noise operation for comfortable working conditions

Applications

• Laboratory vacuum filtration

• Vacuum drying processes

• Rotary evaporator systems

• Chemical and pharmaceutical laboratories

• Analytical laboratory equipment

• General laboratory vacuum systems

Specifications

• Model: SH-CV20

• Pumping Speed (50/60 Hz): 167 L/min

Vacuum Performance

• Ultimate Total Pressure without Gas Ballast: 5 × 10⁻¹ Pa (3.7 × 10⁻³ Torr)

• Ultimate Total Pressure with Gas Ballast: 3 Pa (2.2 × 10⁻² Torr)

Power

• Power Supply: Single Phase

• Power Rating: 3/4 HP

Connections

• Inlet Port: KF25

• Exhaust Port: KF25

Oil System

• Oil Capacity: 0.75 L

Motor

• Motor Speed (50/60 Hz): 1850 rpm

Operating Conditions

• Ambient Temperature: 5 – 40 °C

• Noise Level: ≤ 52 dB to ≤ 58 dB

Physical Specifications

• Weight: 15 kg

Conclusion

The SH-CV20 vacuum pump provides reliable vacuum performance in a compact oil rotary design. Its efficient pumping speed, gas ballast capability, and low noise operation make it suitable for a wide range of laboratory vacuum applications including filtration, drying, and analytical processes.
